T3203-S3001
Floorplan 1
T3203-S3001
Four-unit townhouse plan featuring two 1,485 sq. ft. single-story units and two 2,463 sq. ft. two-story units, plus center-unit garages. Standard basement foundation.
PDF – Single Build
Complete printable PDF construction drawings with permission to build the design one time. Ideal for homeowners, builders, or developers constructing a single project.
Description
Four attached residences create a differentiated townhouse plan designed around two single-story end units and two larger, two-story center units. Each end residence delivers three bedrooms, two baths, 1,485 square feet of heated living area, and 1,832 square feet of total area. The center townhomes expand the offering to 2,463 square feet of heated living area per unit, organized across 1,099 square feet on the first floor and 1,364 square feet upstairs. Three bedrooms, two-and-a-half baths, and attached one-car garages further distinguish the interior residences, giving developers a varied unit mix within one coordinated architectural composition.
Clear separation between shared living areas and quieter bedroom zones supports intuitive movement, privacy, and daily usability across both floor-plan types. The single-story end residences answer demand for complete one-level living, while the center units introduce additional square footage and vertical separation for residents seeking a more expansive layout. Altogether, the building provides 7,896 square feet of interior heated area. The repeated unit relationships, balanced exterior massing, and strategic variation between end and center residences position T3203-S3001 as a practical multifamily plan offering disciplined square-footage use, resident appeal, and buildable value for developers, builders, and investment-property teams.
Plan Highlights
- Four-unit attached townhouse plan
- Two single-story end residences
- Two two-story center residences
- Three bedrooms per unit
- Two baths in each single-story end unit
- Two-and-a-half baths in each two-story center unit
- 1,485 square feet of heated living area per end unit
- 2,463 square feet of heated living area per center unit
- Center-unit heated area includes 1,099 square feet on the first floor and 1,364 square feet on the second floor
- 7,896 square feet of total interior heated area
- Attached one-car garages serving the two center units
Important Information
Modifications Available. Thoughtful adjustments can help tailor this plan to your project, market, and building requirements.
Due to variations in soil conditions, climate, local codes, and site requirements, these construction documents are not engineered or sealed by an architect. Local professional review may be required before construction.
| Designer Plan Number | T3203-S3001 |
|---|---|
| Bedrooms Per Unit | 3 |
| Bathrooms per Unit | 2.5 |
| Plan Width | 124 ' 4 " |
| Plan Depth | 56 ' 6 " |
| Main Ceiling | 9 ' 0 " |
| 2nd Ceiling | 0 ' 0 " |
| Foundation Standard Basement | yes |
| Roof Pitch | 7 in 12 |
| Building Floors | 2 |
|---|---|
| Unit Floors | 1 |
| First Floor Area | 1099 sq.ft |
| 2nd Floor Area | 1364 sq.ft |
| Total Living Area | 7896 sq.ft |
| Total Plan Area | 7896 sq.ft |
| Garage Bays Per unit | 1 |
| Garage Type | Attached |
